UVX Tin-Side Sensor

UVX Tin-Side Sensor

  • High-speed
  • Numeral display
  • Calibration option
  • Discrete & analog outputs

$258.99$3,010.99

SKU : N/A Categories : , ,

Overview of the UVX™ Series, Tin Side Detector

Our UVX™ tin side detector employs a field-proven UVX™ sensor and tin side mini to deliver reliable detection for float glass manufacturing. Glass processors now have an easily integrable solution to identify the tin side of float glass.

Control Unit

Our tin side detector control unit provides a display with a 00-99 range and access to set-up
parameters and threshold adjustment. The output of the control unit is a discrete
NPN/PNP signal, that indicates when the signal level exceeds the threshold setting which
occurs when viewing the tin side. The control unit may be mounted to provide easy
access to the controls and display.

Optical Sensor Unit

The optical sensor unit is mounted approximately 5-10mm from the surface of the
glass. A green LED indicates power. The enclosure provides 2 mounting holes for
customer-supplied bracket/hardware. Our optical unit also functions as a shroud
over the sampling area to minimize exposure to the UV light source and prevent
interference from ambient light. The light source is field replaceable by properly
trained technicians.



How the UVX™ Tin-Side Sensor Works:

  • The UVX™ series system consists of a control unit, optical unit, 24VDC power supply, and interface cable.
  • The control unit provides a display with a 00-99 range and access to set-up parameters and threshold adjustment.
  • The output of the control unit is a discrete, NPN/PNP that indicates when the signal level exceeds the threshold setting which occurs when viewing the tin-side.
  • The control unit may be mounted to provide easy access to the controls and the display.



Applications:



 Have Questions? CLICK HERE

Features of UVX™ Tin-Side Sensor

  • Small spot size
  • Remote mounted display and control
  • Display range 00-99
  • Fast response
  • Adjustable gain
  • Analog outputs and PNP/NPN discrete output
  • Easy-to-use Teach Mode to set up parameters and threshold detection
Model Number UVX Tin-Side Mini
Display Range 0-99
Sensitivity Special
Spectral Sensitivity 400-700nm
Operating Range 5-10mm
Gain Selections Adjustable
Discrete Output PNP/NPN

Tin-side detection of float glass

The UVX Tin-Side sensor reliably detects the presence of the tin-side of float glass. The system consists of a Control Unit, Optical Unit, 24VDC power supply and interface cable.
